Netvio JPEG2000 1Gb 4K/60 HDR decoder | 1080p preview, IR, RS-232, CEC, USB2.0 KVM, video wall, enterprise security.

Price Match
£690.48
Netvio JPEG2000 1Gb 4K/60 HDR decoder | 1080p preview, IR, RS-232, CEC, USB2.0 KVM, video wall, enterprise security.
Price Match
£690.48
in stock
Netvio JPEG2000 1Gb 4K/60 HDR decoder | 1080p preview, IR, RS-232, CEC, USB2.0 KVM, video wall, enterprise security. Product code: IP-JP4-RX-10 £690.48  Inc. VAT
Want it delivered Tomorrow?
£9.99 Next working day  (11am cut-off, on most products we'll advise if not available)
£3.99 Standard delivery 2 - 4 working days (free on orders over £150)
Ask a Question
Please enter your details and we will get back to you.
Description
Delivery

The NET-IP-JP4-RX-10 JPEG2000 high performance Decoder from Netvio converts 1Gb IP streams to HDMI for direct connection to display devices. It delivers multi functional solution for all of your audio, data, video, KVM, video wall and control needs.

Netvio, a professional AV company, provides a fresh and creditable brand alternative with a different perspective towards product integration, hardware and software. Netvio aims to redefine and expand video product functionality beyond traditional standards whilst also providing the best overall value and user experiences.

The NET-IP-JP4-RX-10 JPEG2000 high performance Decoder from Netvio converts 1Gb IP streams to HDMI for direct connection to display devices. It delivers multi functional solution for all of your audio, data, video, KVM, video wall and control needs.

With the latest 4K/60 HDR using Cat5e/6 cables, this decoder supports 40m and 70m output lengths. If bandwidth exceeds HDBaseT 10.2Gbps limits, then seamless light compression is added. This JPEG2000 decoder converts IP streams from 4K/60 HDR HDMI media to bandwidths of less than 1Gb allowing content delivery distribution over a standard IP network.

Having low latency means faster responses. The NET-IP-JP4-RX-10 meets low latency (1-frame) expectations even for the most demanding of applications where little perceptible differences between user interaction and real time screen content is required. Whilst the onboard scaling solves a reoccurring problem on how to seamlessly integrate the latest 4K/60 HDR displays with older legacy 2K equipment.

The routing of audio and video signals are independent. Meaning connections to local audio system use variable line level stereo with the media switch. This decoder also offers you the security needed for your installation. With Enterprise Encryption the decoder 's communications  are secured by SSH encryption and the controller to LAN connectivity is by WSS. Internal and external browsers are secured by HTTPS and TLS, including custom certificates.

The touch interfaces are by USB2.0 extension and KVM function provides a bridge between PCs, peripherals and displays allowing users to control multiple host and client devices over one AVoIP solution. The integrated video wall processing replaces the need for dedicated hardware. This decoder can create a range of configurations up to 81 displays (9 x 9).

1080p full HD stunning 1080p real time preview streams are delivered by HQ previews, which are embedded in the latest Netvio GO end user control application. Can be securely applied to other software decoding applications.

In addition to these many features, Netvio offer free on board facilities such as Netvio GO and Netvio 360. Netvio GO is a case of GET, SET, GO, providing a high quality end user control experience for HDBaseT, 1Gb and 10Gb AVoIP solutions. It is a full spectrum AV control platform using Apple and Android devices, Netvio GO seamlessly manages signal distribution, media sources, displays and audio devices via IR, RS-232, CEC and IP without dedicated control hardware.

Netvio 360  provides you the opportunity to discover, configure, optimise, design and control. And it is as easy as that.  It is a free utility for PC and Mac provides a unified and guided workflow approach to discover, configure, optimise, design and control HDBaseT, 1Gb and 10Gb AVoIP solutions. It is simply the fastest  user friendly AVoIP configurator.

This Netvio JPEG2000 decoder comes with mounting brackets, IR accessories and phoenix connectors.  Everything you need to set up and get going.

Please Note:Completion of Netvio training is required before access to this product. Please contact Habitech on 01256 638500 for further details.

This JPEG2000 high performance decoder converts 1Gb IP streams to HDMI for direct connection to display devices

It delivers multi functional solution for all of your audio, data, video, KVM, video wall and control needs

With the latest 4K/60 HDR using Cat5e/6 cables, this decoder supports 40m and 70m output lengths

Netvio's decoder converts IP streams from 4K/60 HDR HDMI media to bandwidths of less than 1Gb allowing content delivery distribution over a standard IP network

It meets low latency (1-frame) expectations even for the most demanding of applications where little perceptible differences between user interaction and real time screen content is required

Onboard scaling solves a reoccurring problem on how to seamlessly integrate the latest 4K/60 HDR displays with older legacy 2K equipment

Connections to local audio system use variable line level stereo with the media switch

With Enterprise Encryption the decoder 's communications  are secured by SSH encryption and the controller to LAN connectivity is by WSS

Internal and external browsers are secured by HTTPS and TLS, including custom certificates

Touch interfaces are by USB2.0 extension and KVM function provides a bridge between PCs, peripherals and displays allowing users to control multiple host and client devices over one AVoIP solution

This decoder can create a range of configurations up to 81 displays (9 x 9)

1080p full HD stunning 1080p real time preview streams are delivered by HQ previews, which are embedded in the latest Netvio GO end user control application

Netvio offer free on board facilities such as Netvio GO and Netvio 360 apps

Cost effective SafeGuard enhanced product protection for up to 10 years for 10% additional cost

It comes with mounting brackets, IR accessories and phoenix connectors.  Everything you need to set up and get going

Features

  • NET-IP-JP4-RX-10 Netvio JPEG2000 1Gb 4K/60 HDR Decoder
  • Encoding Data Rate HDMI input: Max 17.82Gb/s
  • LAN output: Max 850Mb/s
  • Preview output: Max - 20.48Mb/s + 2048Kb/s
  • USB throughput: Max - 60Mb/s
  • Max Video Transmission 3840 x 2160 60fps 8b 4:2:2
  • IP preview main output: 1920 x 10802 30fps
  • IP preview sub output: 960 x 5802 30fps
  • HDMI 3840 x 2160 60fps 8b 4:4:4
  • HDMI HDMI 2.0 compatible 6Gbs 600MHz TMDS (e.g. 3840 x 2160 60fps 4:4:4 8b) via HDMI type A receptacle

Technical Specifications

  • CEC, DDC
  • Max Pixel Clock 300MHz / 300Mcsc
  • HDR Compatibility HDR10, HDR10+, Hybrid Log Gamma, Dolby® Vision
  • Scaler Function 4K to 2K 8b
  • Modes include, pass through (no scaling), fixed 4K → 2K, automatic
  • HDCP Inclusive up to 2.2
  • Audio Formats LPCM 2ch, LPCM 5.1, LPCM 7.1, Dolby® Digital, Dolby® Digital Plus, Dolby® TrueHD, DTS, DTS Master
  • LAN 1 x IEEE 802.3u 100Base-TX Ethernet interface via RJ45 socket
  • Local discovery and API console via Netvio 360 and Netvio Go App
  • 3rd party integration via public API
  • Delivery Separate multicast group IPs for audio, video, infrared, serial, CEC, USB
  • Link manager via single multicast group IP from query device. Response via unicast
  • Default API channel via unicast, secured using SSH protocol
  • Preview, Unicast RTSP protocol for media management of audio/video
  • End to End Latency HDMI: HDMI pass through zero frames
  • HDMI path using compatible decoder = 1 video frame
  • HDMI path using compatible decoder with scaling = 2 video frames
  • Preview: ~1s (varies, no fixed clock) plus decoder latency
  • USB Supports KVM mode for multiple USB devices (decoder) to USB host (encoder) data routing, device emulation and data contention mitigation
  • RS-232 Supports serial generation and reception. Also supports serial routing from encoder -> decoder(s) and decoder -> encoder(s)
  • IR Supports Infrared generation and reception. Also supports IR routing from encoder -> decoder(s) and decoder -> encoder(s
  • Drivers and Control Drivers available for control systems including C4, Crestron, RTi and Elan
  • Discovery, configure, optimise, design via Netvio 360 utility
  • Full spectrum AV control via free Netvio apps for Apple and Android devices
  • EDID Automatic, onboard pre-sets, copy sync (RX)
  • Power Supply PoE / PoE+ IEEE 802.3af compliant (12W draw)
  • Safety Approvals CE, UKCA, FCC, RoSH
  • Dimensions Height: 22mm / 0.87"
  • Width: 204mm / 8.03"
  • Depth: 100mm / 3.94"
  • Weight: 0.5kg
  • Warranty 2 year standard warranty
  • 3 year standard warranty (subject to online registration)
  • 5 year SafeGuard - 5% product value
  • 10 year SafeGuard - 10% product value
