Netvio 70m 4K/60 HDR | 100m 1080p | HDBaseT extender with Ethernet, ARC, 2-way IR, RS-232 & 2-way PoC.
Netvio delivers the full benefit of HDBaseT with 5 Play with the NET-EX-HT2-701-10 HDBaseT Extender supporting 4K/60 HDR and 1080p With Ethernet and ARC. It offers audio, video, control, Ethernet and power over single a Cat5e/6/7 cable. Power either TX or RX for added convenience. This HDBaseT extender has everything covered for the most demanding of applications.
Netvio, a professional AV company, provides a fresh and creditable brand alternative with a different perspective towards product integration, hardware and software. Netvio aims to redefine and expand video product functionality beyond traditional standards whilst also providing the best overall value and user experiences.
Netvio delivers the full benefit of HDBaseT with 5 Play with the NET-EX-HT2-701-10 HDBaseT Extender supporting 4K/60 HDR and 1080p With Ethernet and ARC. It offers audio, video, control, Ethernet and power over single a Cat5e/6/7 cable. Power either TX or RX for added convenience. This HDBaseT extender has everything covered for the most demanding of applications.
This extender delivers 4K/60 HDR across Cat5e/6 with 70m support. If the media demands exceed 10.2Gbps then seamless compression is added. Capturing ARC from either embedded HDMI or S/PDIF. TX device provides the ability to select audio from display HDMI, S/PDIF or TX audio. This provides easy connection to the audio system. Using the same single category cable as AV functionality, 100BaseT Ethernet is a perfect network connection solution for smart TVs, IP control or adding a wireless access point. Secure hardwired bi-directional serial control between source and display. Extender kit comes complete with 3 pin screw type connectors for ease of installation.
HDBaseT provides useful troubling shooting status indicators showing status of connection and source content.
Each Netvio extender kit comes complete with all required accessories to fully maximise product features and functionality.
Please Note: Netvio recommend the use of approved IR accessories to ensure guaranteed performance and compatibility. In perfect conditions, IR performance is rated at 8m from display to remote control, but this will vary in differing light conditions. It may be necessary to adjust both the capture, sender device positions to achieve best performance, ensuring that remote batteries are in good condition.
Features
- 70m 4K/60 HDR HDBaseT Extender with full 5 play features including audio, video, control, data and power
- Compatible with all latest standards including HDMI2.0b and HDCP2.2
- Supporting latest (18Gb) digital audio and video standards including HDR-10, HLG, Dolby® Vision, DTS-X and Dolby® Atmos
- Accepts popular high bandwidth media sources providing seamless transport over a dedicate HDBaseT AV network using Cat5e/6 cables
- 100BaseT Ethernet Pass-Thru
- HDMI or S/PDIF ARC capture: Switchable TX with both analogue and digital audio output connections
- 2 way power over cable (PoC)
- PSU connection at either TX or RX
- 2-Way IR control. RX>TX, TX>RX
- Direct bi-directional RS-232
- Each Netvio extender kit comes complete with all required accessories to fully maximise product features and functionality
- Cost effective SafeGuard enhanced product protection for up to 10 years for 10% additional cost
Technical Specifications
- NET-EX-HT2-701-10 HDBaseT Extender: 4K/60 HDR and 1080p With Ethernet and ARC
- Encoding Data Rates HDMI 17.82 Gbp
- HDBaseT 10.2Gbs
- Visually lossless compression > 10.Gbs
- Video Resolutions (Max) 3840 x 2160 60fps HDR over 70m Cat5e/6/7 cable (1080p @ 100m)
- Max Pixel Clock 600MHz
- HDR HDR10, HDR10+, Hybrid Log Gamma, Dolby® Vision
- HDCP Inclusive up to 2.2
- EDID Automatic HDMI sink from RX to TX
- Audio Formats LPCM 2ch, LPCM 5.1, LPCM 7.1, Dolby® Digital, Dolby® Digital Plus, Dolby® TrueHD, DTS,
- DTS Master, Dolby® Atmos and DTS:X.
- HDBaseT Supports CEC, DDC, 100BaseT Ethernet, RS-232 TXD, RXD and Infrared
- RS-232 Direct RS-232 Serial interface (3 pin) via Phoenix style, 3.5mm pitch male receptacle
- IR Bi-directional infrared, TX > RX, RX > TX via 3.5mm jack sockets
- Please see additional information in the Download Section for wiring schematic
- Power Supply 24V external PSU supporting power-over-cable (PoC). PSU can be connected to either TX or RX
- Environment Operating temperature: 0°C / 32°F to 40°C / 104°F
- Storage temperature: -20°C / -4°F to 60°C / 140°F
- Relative humidity: 20% to 90%
- Safety Approvals CE, UKCA, FCC, RoHS
- Dimensions Per Device Height: 20mm / 0.79"
- Width: 165mm / 6.50"
- Depth: 88mm / 3.47"
- Weight: 170g
- Warranty 2 year standard warranty
- 3 year standard warranty (subject to online registration)
- 5 year SafeGuard - 5% product value
- 10 year SafeGuard - 10% product value
- In The Box Mounting brackets
- IR Accessories
- Phoenix Connectors
- 24V PSU
