Netvio Fixed head HDMI optical | Uncompressed 18Gb 4K/60 HDR, LSZH, with ARC, CEC support.

Price Match
£144.90 - £186.48
Netvio Fixed head HDMI optical | Uncompressed 18Gb 4K/60 HDR, LSZH, with ARC, CEC support.
Price Match
£144.90 - £186.48
in stock
Product code:
Want it delivered by Wednesday, 9th Oct?
£9.99 Next working day  (11am cut-off, on most products we'll advise if not available)
£3.99 Standard delivery 2 - 4 working days (free on orders over £150)
Ask a Question
Please enter your details and we will get back to you.
Description
Delivery

The WyreStorm HAOC is a next generation HDMI cable designed for 8K and 4K HDR content. Offering pixel perfect long distance transmission of content and native HDMI communication, they deliver uncompressed HDMI content and compatibility with emerging HDMI technologies such as ALLM (Auto Low Latency Mode) and VRR (Variable Refresh Rate). Available in 10m and 15m lengths.

Frequently adopted for use in powerful HDBaseT Extenders such as WyreStorm’s EX-100-H2-PRO, the VESA approved Display Stream Compression technology is now being used in native HDMI connections. The aim to send super high bandwidth content at a lower transmission data rate is achieved by WyreStorm’s FRL HAOC cables, which are compatible with this technology and will safely pass the signal from source to display.

Adopting a powerful 48Gbps 4 core transmission system, the passive optical transmission within these FRL cables is compatible with new content exceeding the current HDMI 2.0 standard. With each core rated at 12Gbps, the combined bandwidth means that the CAB-HAOC-FRL will support future content up to 48Gbps, equating to 8K/60 4:4:4 using peer to peer DSC. HDMI technology works by sending huge amounts of invisible “metadata” in both directions and it’s this information that influences a viewing experience.

WyreStorm Active Optical Cables have been verified to ensure that the A/V signal and invisible metadata gets to its destination. eARC, CEC, ALLM, and VRR are all supported by WyreStorm HAOC-FRL cables.

The emergence of HDR has led to there being several methods of displaying deeper colour palettes. HDR-10 and HLG and licensed versions like Dolby Vision and SL-HDR1 are all currently competing formats that all vary in their method of effectively achieving the same end result. WyreStorm’s HAOC cable, being a transparent transmission medium, support all known HDR standards and send them uncompressed.

Available in 10m and 15m lengths.

Features

  • Uncompressed Optical Transmission of HDMI Content Up To 48Gbps: 2K (2560 x 1440p) 240Hz, 4K (4096 x 2160p) 144Hz, 5K (5120 x 2880p) 60Hz, 8K (7680 x 4320p) 60Hz. Timings listed are quoted as 4:4:4 8-bit
  • Compatible With All Current And Emerging HDR Standards: HLG (Hybrid Log Gamma), HDR-10 and HDR-10+, Dolby Vision, PQ (Perceptual Quantizer) and SL-HDR-1
  • Ready for future HDCP 2.3 content encryption
  • Compatible with new eARC HD audio standard for on demand content from smart TV’s
  • Supports HDMI2.1 FRL (Fixed Rate Link) 16/18b encoding and DSC (Display Stream Compression)
  • True native HDMI communication ensures CEC and audio return communication between compatible devices
  • Supports new HDMI2.1 features such as ALLM (Auto Low Latency Mode) and VRR (Variable Refresh Rate)
  • Perfect for use in environments with excessive EM or RF interference
  • Kevlar protected communication cores
  • High quality aluminium construction with low profile 20mm/0.79” TX head
  • Supplied coiled on cardboard spool inbox, with RX head out first.
  • No single use plastic included* #SUPFree
  • Available in 10m and 15m lengths

Tchnical Specifications

  • Transmission Encoding Uncompressed AOC (with DSC Support between source display when required)
  • End to End Latency 10µs
  • Maximum Transmission Bit Rate 48Gbps (4 core, 12Gbps per lane)
  • HDMI (v2.0b) TMDS |600MHz maximum
  • (v2.1) FRL (fixed rate link) 16b / 18B encoding
  • DSC (Display Stream Compression) Supported
  • Supported Video Resolutions 1920 x 1080p @240Hz
  • 2560 x 1440p @240Hz
  • 3840 x 2160p @144Hz
  • 5120 x 2880p @60Hz
  • 7680 x 4320 @60Hz
  • Supported Standards DSC, Static HDR, HDR10+, Dolby Vision, HLG, SL-HDR1,  PQ, BT.2020 and BT.2100
  • Audio Formats 2ch PCM,  Multichannel LPCM,  DTS-X, Dolby Atmos
  • Enhanced Audio Return Channel
  • (eARC) Supported
  • Auto Low Latency Mode (ALLM) Supported
  • Variable Refresh Rate (VRR) Supported
  • Max Bend Radius 2cm
  • Max Pull Tension 15kg / 33lbs
